如何拆卸和安裝約翰迪爾強鹿柴油機燃油系統儲液罐6125ADW01/70發動機,
Remove and Install Fuel System Surge Tank (6125ADW01/70 Engines)

1. Disconnect fuel line from adapter (C) (shown disconnected).
2. Disconnect fuel line (E).
Cap and plug all lines and fittings to prevent fuel system contamination.
3. Remove surge tank (A) from mounting bracket (B).
4. If fuel line adapters (C) and (F) are removed,  install
A—Surge Tank
Surge Tank
new O-rings in adapters and install adapters in surge tank. Tighten adapters to the following specifications.
Specification
Surge Tank Fuel Line Adapter
(Top)—Torque .................................................................  46 N•m (34 lb-ft)
Surge Tank Fuel Line Adapter
(Bottom)—Torque ............................................................  39 N•m (29 lb-ft)
B—Mounting Bracket
C—Line Adapter (Fuel Tank Return Line) D—Label (Marked “TOP”)
E—Fuel Line (Surge Tank-to-Fuel Manifold) F—Line Adapter (Fuel Manifold Line)
5. If removed, install mounting bracket (B) and tighten cap screws to specifications.
Specification

Surge Tank Mounting
Bracket-to-Cylinder Head Cap
Screws—Torque ............................................................  130 N•m (95 lb-ft)
6. Install surge tank on mounting bracket with end labeled “TOP” (D) in the up position as shown. Center cap screws in surge tank slots and tighten to  specifications.
Specification
Surge Tank-to-Mounting Bracket
Cap Screws—Torque ......................................................  50 N•m (37 lb-ft)
7. Connect fuel lines and tighten to specifications.
Specification
Surge Tank Fuel Lines—Torque .....................................  24 N•m (18 lb-ft)
